Democratizing content publication with Coral
Michael J. Freedman, Eric Freudenthal, David Mazières
New York University
http://www.scs.cs.nyu.edu/coral/
Abstract:
CoralCDN is a peer-to-peer content distribution network that allows a
user to run a web site that offers high performance and meets huge
demand, all for the price of a cheap broadband Internet connection.
Volunteer sites that
run CoralCDN automatically replicate content as a side
effect of users accessing it. Publishing through CoralCDN is as
simple as making a small change to the hostname in an object's URL; a
peer-to-peer DNS layer transparently redirects browsers to nearby
participating cache nodes, which in turn cooperate to minimize load on
the origin web server. One of the system's key goals is to avoid
creating hot spots that might dissuade volunteers and hurt
performance.
It achieves this through Coral,
a latency-optimized hierarchical indexing infrastructure based on
a novel abstraction called a distributed sloppy hash
table,
or DSHT.
1 Introduction
The availability of content on the Internet is to a large degree a
function of the cost shouldered by the publisher. A well-funded web
site can reach huge numbers of people through some combination of
load-balanced servers, fast network connections, and commercial
content distribution networks (CDNs). Publishers who cannot afford
such amenities are limited in the size of audience and type of content
they can serve. Moreover, their sites risk sudden overload following
publicity, a phenomenon nicknamed the ``Slashdot'' effect, after a
popular web site that periodically links to under-provisioned servers,
driving unsustainable levels of traffic to them. Thus, even
struggling content providers are often forced to expend significant
resources on content distribution.
Fortunately, at least with static content, there is an easy way for
popular data to reach many more people than publishers can afford to
serve themselves---volunteers can mirror the data on their own servers
and networks. Indeed, the Internet has a long history of
organizations with good network connectivity mirroring data they
consider to be of value. More recently, peer-to-peer file sharing has
demonstrated the willingness of even individual broadband users to
dedicate upstream bandwidth to redistribute content the users
themselves enjoy.
Additionally, organizations that mirror
popular content reduce their downstream bandwidth utilization and
improve the latency for local users accessing the mirror.
This paper describes CoralCDN, a decentralized, self-organizing,
peer-to-peer web-content distribution network. CoralCDN leverages the
aggregate bandwidth of volunteers running the software to absorb and
dissipate most of the traffic for web sites using the system. In so
doing, CoralCDN replicates content in proportion to the content's
popularity, regardless of the publisher's resources---in effect
democratizing content publication.
To use CoralCDN, a content publisher---or someone posting a link to
a high-traffic portal---simply appends ``.nyud.net:8090'' to
the hostname in a URL. Through DNS redirection, oblivious clients
with unmodified web browsers are transparently redirected to nearby
Coral web caches. These caches cooperate to transfer data from
nearby peers whenever possible, minimizing both the load on the origin
web server and the end-to-end latency experienced by browsers.
CoralCDN is built on top of a novel key/value indexing
infrastructure called Coral. Two properties make Coral ideal
for CDNs. First, Coral allows nodes to locate nearby cached copies
of web objects without querying more distant nodes. Second, Coral
prevents hot spots in the infrastructure, even under degenerate loads.
For instance, if every node repeatedly stores the same key, the rate
of requests to the most heavily-loaded machine is still only
logarithmic in the total number of nodes.
Coral exploits overlay routing techniques recently popularized by a
number of peer-to-peer distributed hash tables (DHTs). However, Coral
differs from DHTs in several ways. First, Coral's locality and hot-spot
prevention properties are not possible for DHTs. Second, Coral's
architecture is based on clusters of well-connected machines.
Clusters are exposed in the interface to higher-level software, and in
fact form a crucial part of the DNS redirection mechanism. Finally,
to achieve its goals, Coral provides weaker consistency than
traditional DHTs. For that reason, we call its indexing abstraction a
distributed sloppy hash table, or DSHT.
CoralCDN makes a number of contributions. It enables people to
publish content that they previously could not or would not because of
distribution costs. It is the first completely decentralized and
self-organizing web-content distribution network. Coral, the
indexing infrastructure, provides a new abstraction potentially of use
to any application that needs to locate nearby instances of resources
on the network. Coral also introduces an epidemic clustering
algorithm that exploits distributed network measurements.
Furthermore, Coral is the first peer-to-peer key/value index that
can scale to many stores of the same key without hot-spot congestion,
thanks to a new rate-limiting technique. Finally, CoralCDN
contains the first peer-to-peer DNS redirection infrastructure,
allowing the system to inter-operate with unmodified web browsers.
Measurements of CoralCDN demonstrate that it allows
under-provisioned web sites to achieve dramatically higher capacity, and
its clustering provides quantitatively better performance than
locality-unaware systems.
The remainder of this paper is structured as follows.
Section 2 provides a high-level description of
CoralCDN, and Section 3 describes its DNS system and web
caching components.
In Section 4, we describe the Coral
indexing infrastructure, its underlying DSHT layers, and the
clustering algorithms. Section 5 includes
an implementation overview and Section 6 presents
experimental results. Section 7 describes related
work, Section 8 discusses future work, and
Section 9 concludes.
2 The Coral Content Distribution Network
The Coral Content Distribution Network (CoralCDN) is composed of
three main parts: (1) a network of cooperative HTTP proxies that
handle users' requests,1
(2) a network of DNS nameservers for
nyucd.net that map clients to nearby Coral HTTP proxies, and (3)
the underlying Coral indexing infrastructure and clustering
machinery on which the first two applications are built.
2.1 Usage Models
To enable immediate and incremental deployment, CoralCDN is
transparent to clients and requires no software or plug-in
installation. CoralCDN can be used in a variety of ways,
including:
-
Publishers. A web site publisher for x.com can change
selected URLs in their web pages to ``Coralized'' URLs, such as
http://www.x.com.nyud.net:8090/y.jpg.
- Third-parties. An interested third-party---e.g., a
poster to a web portal or a Usenet group---can Coralize a URL
before publishing it, causing all embedded
relative links to use CoralCDN as well.
- Users. Coral-aware users can manually construct
Coralized URLs when surfing slow or overloaded web sites. All
relative links and HTTP redirects are automatically Coralized.
2.2 System Overview
Figure 1 shows the steps that occur when a client
accesses a Coralized URL, such as
http://www.x.com.nyud.net:8090/, using a standard web browser. The
two main stages---DNS redirection and HTTP request handling---both
use the Coral indexing infrastructure.
Figure 1: Using CoralCDN, the steps involved in resolving
a Coralized URL and returning the corresponding
file, per Section 2.2. Rounded boxes
represent CoralCDN nodes running Coral, DNS, and HTTP
servers.
Solid arrows correspond to Coral RPCs, dashed arrows to DNS
traffic, dotted-dashed arrows to network probes, and dotted arrows
to HTTP traffic.
-
A client sends a DNS request for www.x.com.nyud.net to its local
resolver.
- The client's resolver attempts to resolve the hostname using some
Coral DNS server(s), possibly starting at one of the few
registered under the .net domain.
- Upon receiving a query, a Coral DNS server probes the client to
determines its round-trip-time and last few network hops.
- Based on the probe results, the DNS server checks Coral to see if
there are any known nameservers and/or HTTP proxies near the client's
resolver.
- The DNS server replies, returning any servers found through Coral
in the previous step; if none were found, it returns a random set of
nameservers and proxies. In either case, if the DNS server is close
to the client, it only returns nodes that are close to itself (see
Section 3.1).
- The client's resolver returns the address of a Coral HTTP proxy for
www.x.com.nyud.net.
- The client sends the HTTP request
http://www.x.com.nyud.net:8090/ to the specified proxy.
If the proxy is caching the file locally, it returns the file and
stops. Otherwise, this process continues.
-
The proxy looks up the web object's URL in Coral.
- If Coral returns the address of a node caching the object, the
proxy fetches the object from this node. Otherwise, the proxy
downloads the object from the origin server, www.x.com (not
shown).
- The proxy stores the web object and returns it to the client browser.
- The proxy stores a reference to itself in Coral, recording the fact
that is now caching the URL.
2.3 The Coral Indexing Abstraction
This section introduces the Coral indexing infrastructure as used
by CoralCDN. Coral provides a distributed sloppy hash
table (DSHT) abstraction. DSHTs are designed for applications
storing soft-state key/value pairs, where multiple values may be
stored under the same key. CoralCDN uses this mechanism to map a
variety of types of key onto addresses of CoralCDN nodes. In
particular, it uses DSHTs to find Coral nameservers
topologically close clients' networks, to find HTTP proxies caching
particular web objects, and to locate nearby Coral nodes for the
purposes of minimizing internal request latency.
Instead of one global overlay as
in [5, 14, 27], each Coral
node belongs to several distinct DSHTs called clusters.
Each cluster is characterized by a maximum desired network
round-trip-time (RTT) we call the diameter. The system is
parameterized by a fixed hierarchy of diameters known as
levels. Every node is a member of one DSHT at each level.
A group of nodes can form a level-i cluster if a high-enough
fraction their pair-wise RTTs are below the level-i diameter
threshold.
Although Coral's implementation allows for an arbitrarily-deep
DSHT hierarchy, this paper describes a three-level hierarchy with
thresholds of inf, 60 msec, and 20 msec for level-0, -1, and -2
clusters respectively.
Coral queries nodes in higher-level, fast clusters
before those in lower-level, slower clusters. This both reduces the
latency of lookups and increases the chances of returning values
stored by nearby nodes.
Coral provides the following interface to higher-level applications:
-
put (key, val, ttl, [levels]): Inserts a mapping
from the key to some arbitrary value, specifying the time-to-live of
the reference. The caller may optionally specify a subset of the
cluster hierarchy to restrict the operation to certain levels.
- get (key, [levels]): Retrieves some subset of the
values stored under a key. Again, one can optionally specify a subset
of the cluster hierarchy.
- nodes (level, count, [target],
[services]): Returns count neighbors belonging to
the node's cluster as specified by level. target, if
supplied, specifies the IP address of a machine to which the
returned nodes would ideally be near. Coral can probe
target and exploit network topology hints stored in the DSHT
to satisfy the request. If services is specified, Coral
will only return nodes running the particular service, e.g.,
an HTTP proxy or DNS server.
- levels (): Returns the number of levels in Coral's
hierarchy and their corresponding RTT thresholds.
The next section describes the design of CoralCDN's DNS
redirector and HTTP proxy---especially with regard to their use of Coral's
DSHT abstraction and clustering hierarchy---before returning to
Coral in Section 4.
3 Application-Layer Components
The Coral DNS server
directs browsers fetching Coralized URLs to Coral HTTP
proxies, attempting to find ones near the requesting client. These
HTTP proxies
exploit each others' caches in such a way as to minimize both transfer
latency and the load on origin web servers.
3.1 The Coral DNS server
The Coral DNS server, dnssrv, returns IP addresses of Coral
HTTP proxies when browsers look up the hostnames in Coralized URLs.
To improve locality, it attempts to return proxies near requesting
clients. In particular, whenever a DNS resolver (client) contacts a
nearby dnssrv instance, dnssrv both returns proxies within an
appropriate cluster, and ensures that future DNS requests from that
client will not need to leave the cluster. Using the nodes
function, dnssrv also exploits Coral's on-the-fly network
measurement capabilities and stored topology hints to increase the
chances of clients discovering nearby DNS servers.
More specifically, every instance of dnssrv is an authoritative
nameserver for the domain nyucd.net. Assuming a 3-level
hierarchy, as Coral is generally configured, dnssrv maps any
domain name ending http.L2.L1.L0.nyucd.net to one or more
Coral HTTP proxies. (For an (n+1)-level hierarchy, the
domain name is extended out to Ln in the obvious way.)
Because such names are somewhat unwieldy, we established a DNS
dname alias [4], nyud.net, with target
http.L2.L1.L0.nyucd.net. Any domain name ending nyud.net is
therefore equivalent to the same name with suffix
http.L2.L1.L0.nyucd.net, allowing Coralized URLs to have the
more concise form http://www.x.com.nyud.net:8090/.
dnssrv assumes that web browsers are generally close to their
resolvers on the network, so that the source address of a DNS query
reflects the browser's network location. This assumption holds to
varying degrees, but is good enough that Akamai [12],
Digital Island [6], and Mirror Image [21] have all
successfully deployed commercial CDNs based on DNS redirection. The
locality problem therefore is reduced to returning proxies that are
near the source of a DNS request. In order to achieve locality,
dnssrv measures its round-trip-time to the resolver and categorizes
it by level. For a 3-level hierarchy, the resolver will correspond to
a level 2, level 1, or level 0 client, depending on how its RTT
compares to Coral's cluster-level thresholds.
When asked for the address of a hostname ending
http.L2.L1.L0.nyucd.net, dnssrv's reply contains two sections of
interest: A set of addresses for the name---answers to the
query---and a set of nameservers for that name's domain---known as the
authority section of a DNS reply. dnssrv returns addresses
of CoralProxies in the cluster whose level corresponds to the
client's level categorization. In other words, if the RTT between the
DNS client and dnssrv is below the level-i threshold (for the
best i), dnssrv will only return addresses of Coral nodes in
its level-i cluster. dnssrv obtains a list of such nodes with
the nodes function. Note that dnssrv always returns
CoralProxy addresses with short time-to-live fields (30 seconds for
levels 0 and 1, 60 for level 2).
To achieve better locality, dnssrv also specifies the client's IP
address as a target argument to nodes. This causes
Coral to probe the addresses of the last five network hops to the
client and use the results to look for clustering hints in the
DSHTs. To avoid significantly delaying clients, Coral maps these
network hops using a fast, built-in traceroute-like
mechanism that combines concurrent probes and aggressive time-outs to
minimize latency. The entire mapping process generally requires
around 2 RTTs and 350 bytes of bandwidth. A Coral node caches
results to avoid repeatedly probing the same client.
The closer dnssrv is to a client, the better its selection of
CoralProxy addresses will likely be for the client. dnssrv
therefore exploits the authority section of DNS replies to lock a DNS
client into a good cluster whenever it happens upon a nearby
dnssrv. As with the answer section, dnssrv selects the
nameservers it returns from the appropriate cluster level and uses the
target argument to exploit measurement and network hints.
Unlike addresses in the answer section, however, it gives nameservers
in the authority section a long TTL (one hour). A nearby dnssrv
must therefore override any inferior nameservers a DNS client may be
caching from previous queries. dnssrv does so by manipulating the
domain for which returned nameservers are servers. To clients more
distant than the level-1 timing threshold, dnssrv claims to return
nameservers for domain L0.nyucd.net. For clients closer than that
threshold, it returns nameservers for L1.L0.nyucd.net. For clients
closer than the level-2 threshold, it returns nameservers for domain
L2.L1.L0.nyucd.net. Because DNS resolvers query the servers for
the most specific known domain, this scheme allows closer dnssrv
instances to override the results of more distant ones.
Unfortunately, although resolvers can tolerate a fraction of
unavailable DNS servers, browsers do not handle bad HTTP servers
gracefully. (This is one reason for returning CoralProxy addresses
with short TTL fields.) As an added precaution, dnssrv only
returns CoralProxy addresses which it has recently verified
first-hand. This sometimes means synchronously checking a proxy's
status (via a UDP RPC) prior replying to a DNS query. We note further
that people who wish to contribute only upstream bandwidth can flag
their proxy as ``non-recursive,'' in which case dnssrv will only
return that proxy to clients on local networks.
3.2 The Coral HTTP proxy
The Coral HTTP proxy, CoralProxy, satisfies HTTP requests for
Coralized URLs. It seeks to provide reasonable request latency and
high system throughput, even while serving data from origin servers behind
comparatively slow network links such as home broadband connections.
This design space requires particular care in minimizing load on
origin servers compared to traditional CDNs, for two reasons. First,
many of Coral's origin servers are likely to have slower network
connections than typical customers of commercial CDNs. Second,
commercial CDNs often collocate a number of machines at each
deployment site and then select proxies based in part on the URL
requested---effectively distributing URLs across proxies. Coral,
in contrast, selects proxies only based on client locality. Thus, in
CoralCDN, it is much easier for every single proxy to end up fetching a
particular URL.
To aggressively minimize load on origin servers, a CoralProxy must
fetch web pages from other proxies whenever possible. Each proxy
keeps a local cache from which it can immediately fulfill requests.
When a client requests a non-resident URL, CoralProxy first
attempts to locate a cached copy of the referenced resource using
Coral (a get), with the resource indexed by a SHA-1 hash of
its URL [22]. If CoralProxy discovers that one or more
other proxies have the data, it attempts to fetch the data from the
proxy to which it first connects. If Coral provides no referrals
or if no referrals return the data, CoralProxy must fetch the
resource directly from the origin.
While CoralProxy is fetching a web object---either from the origin or
from another CoralProxy---it inserts a reference to itself in its
DSHTs with a time-to-live of 20 seconds. (It
will renew this short-lived reference until it completes the
download.) Thus, if a flash crowd suddenly fetches a web page,
all CoralProxies, other than the first simultaneous requests,
will naturally form a kind of multicast tree
for retrieving the web page. Once any CoralProxy obtains the full
file, it inserts a much longer-lived reference to itself (e.g.,
1 hour). Because the insertion algorithm accounts for TTL, these
longer-lived references will overwrite shorter-lived ones,
and they can be stored on well-selected nodes even under high
insertion load, as later described in Section 4.2.
CoralProxies periodically renew referrals to resources in
their caches. A proxy should not evict a web object from its cache
while a reference to it may persist in the DSHT. Ideally, proxies
would adaptively set TTLs based on cache capacity, though this is not
yet implemented.
4 Coral: A Hierarchical Indexing System
This section describes the Coral indexing infrastructure, which
CoralCDN leverages to achieve scalability, self-organization, and
efficient data retrieval. We describe how Coral implements the
put and get operations that form the basis of its distributed sloppy hash table (DSHT) abstraction: the underlying
key-based routing layer (4.1), the DSHT algorithms
that balance load (4.2), and the changes that enable
latency and data-placement optimizations within a hierarchical set of
DSHTs (4.3). Finally, we describe the clustering
mechanisms that manage this hierarchical structure
(4.4).
4.1 Coral's Key-Based Routing Layer
Coral's keys are opaque 160-bit ID values; nodes are assigned
IDs in the same 160-bit identifier space. A node's ID is
the SHA-1 hash of its IP address.
Coral defines a distance metric on IDs. Henceforth, we describe a
node as being close to a key if the distance between the key
and the node's ID is small.
A Coral put operation stores a key/value pair at a node close
to the key. A get operation searches for stored key/value pairs
at nodes successively closer to the key. To support these operations,
a node requires some mechanism to discover other nodes close to any
arbitrary key.
Every DSHT contains a routing table. For any key k, a node R's
routing table allows it to find a node closer to k, unless R is
already the closest node.
These routing tables are based on Kademlia [17],
which defines the distance between two values in the ID-space to be
their bitwise exclusive or (XOR), interpreted as an unsigned integer.
Using the XOR metric, IDs with longer matching prefixes (of most
significant bits) are numerically closer.
The size of a node's routing table in a DSHT is logarithmic in the
total number of nodes comprising the DSHT. If a node R is not
the closest node to some key k, then R's routing table almost
always contains either the closest node to k, or some node whose
distance to k is at least one bit shorter than R's.
This permits R to visit a sequence of nodes with monotonically
decreasing distances [d1, d2, ...] to k, such that the
encoding of di+1 as a binary number has one fewer bit than
di.
As a result, the expected number of iterations for R to discover the
closest node to k is logarithmic in the number of nodes.
Figure 2: Example of routing operations in a
system containing eight nodes with IDs {4, 5, 7, 0, 2, 3, 13,
14}. In
this illustration, node R with id=14 is looking up the node
closest to key k=4, and we have sorted the nodes by their
distance to k. The top
boxed row illustrates XOR distances for the nodes
{0,2,3,13,14} that are initially known by R.
R first contacts a known peer whose distance to k is closest to
half of R's distance (10/2=5); in this
illustration, this peer is node
zero, whose distance to k is 0 XOR 4 =4.
Data in RPC requests and responses are shown in
parentheses and braces, respectively:
R asks node zero for its peers that are half-way
closer to k, i.e., those at
distance 4/2=2. R inserts these new references
into its routing table (middle row).
R now repeats this process, contacting node five, whose distance 1 is
closest to 4/2. Finally, R contacts node four, whose distance
is 0,
and completes its search (bottom row).
Figure 2 illustrates the Coral routing algorithm,
which successively visits nodes whose distances to the key are
approximately halved each iteration. Traditional key-based routing
layers attempt to route directly to the node closest to the key
whenever possible [25, 26, 31, 35],
resorting to several intermediate hops only when faced with incomplete
routing information. By caching additional routing state---beyond the
necessary log(n) references---these systems in practice manage to
achieve routing in a constant number of hops. We observe that
frequent references to the same key can generate high levels of
traffic in nodes close to the key. This congestion, called tree
saturation, was first identified in shared-memory interconnection
networks [24].
To minimize tree saturation, each iteration of a Coral search
prefers to correct only b bits at a time.2 More specifically, let
splice(k,r,i) designate the most significant bi bits
of k followed by the least significant 160-bi bits of r. If
node R with ID r wishes to search for key k, R first
initializes a variable t r. At each iteration, R updates
tsplice(k,t,i), using the smallest value of i that
yields a new value of t. The next hop in the lookup path is the
closest node to t that already exists in R's routing table. As
described below, by limiting the use of potentially closer known hops
in this way, Coral can avoid overloading any node, even in the
presence of very heavily accessed keys.
The potential downside of longer lookup paths is higher lookup latency
in the presence of slow or stale nodes. In order to mitigate these
effects, Coral keeps a window of multiple outstanding RPCs during a
lookup, possibly contacting the closest few nodes to intermediary
target t.
4.2 Sloppy Storage
Coral uses a sloppy
storage technique that caches key/value pairs at nodes whose IDs
are close to the key being referenced.
These cached values reduce hot-spot congestion
and tree saturation throughout the indexing infrastructure:
They frequently satisfy put and get requests at nodes other
than those closest to the key.
This characteristic differs from
DHTs, whose put operations all proceed to nodes closest to the key.
The Insertion Algorithm.
Coral performs a two-phase operation to insert a key/value pair.
In the first, or ``forward,'' phase, Coral routes to nodes that are
successively closer to the key, as previously described. However, to
avoid tree saturation, an insertion operation may terminate prior to
locating the closest node to the key, in which case the key/value pair
will be stored at a more distant node. More specifically, the forward
phase terminates whenever the storing node happens upon another node
that is both full and loaded for the key:
-
A node is full with respect to some key
k when it stores l values for k whose TTLs are all at
least one-half of the new value.
- A node is loaded with respect to k when it has received more
than the maximum leakage rate B requests for k within
the past minute.
In our experiments, l=4 and B=12, meaning that under
high load, a node claims to be loaded for all but one store attempt
every 5 seconds. This prevents excessive numbers of requests from
hitting the key's closest nodes, yet still allows enough requests to
propagate to keep values at these nodes fresh.
In the forward phase, Coral's routing layer makes
repeated RPCs to contact nodes successively closer to
the key.
Each of these remote nodes returns (1) whether the key is loaded and
(2) the number of values it stores under the key, along with
the minimum expiry time of any such values.
The client node uses this information to determine if the remote node
can accept the store, potentially evicting a value with a shorter
TTL. This forward phase terminates when the client node finds
either the node closest to the key, or a node that is full and loaded
with respect to the key.
The client node places
all contacted nodes that are not both full and loaded on a
stack, ordered by XOR distance from the key.
During the reverse phase, the client node attempts to insert the value
at the remote node
referenced by the top stack
element, i.e., the node closest to the key. If this operation
does not succeed---perhaps due to others' insertions---the client node
pops the stack and tries to insert on the new stack top.
This process is repeated
until a store succeeds or the stack is empty.
This two-phase algorithm avoids tree saturation by storing values
progressively further from the key. Still, eviction and the leakage
rate B ensure that nodes close to the key retain long-lived
values, so that live keys remain reachable: B nodes per minute
that contact an intermediate node (including itself) will go on to
contact nodes closer to the key.
For a perfectly-balanced tree, the key's closest node receives only
(B · (2b-1) · O((logn)/b))
store requests per minute, when fixing b bits per iteration.
Proof sketch. Each node in a system of n nodes can be
uniquely identified by a string S of logn bits. Consider S to
be a string of b-bit digits. A node will contact the closest node
to the key before it contacts any other node if and only if its ID
differs from the key in exactly one digit. There are
O((logn)/b) digits in S. Each digit can
take on 2b-1 values that differ from the key. Every node that
differs in one digit will throttle all but B requests per
minute. Therefore, the closest node receives a maximum rate of
(B · (2b-1) · O((logn)/b))
RPCs per minute.
Irregularities in the node ID distribution may increase this rate
slightly, but the overall rate of traffic is still logarithmic, while
in traditional DHTs it is linear. Section 6.4
provides supporting experimental evidence.
The Retrieval Algorithm.
To retrieve the value associated with a key k, a node simply traverses the ID
space with RPCs.
When it finds a peer storing k, the remote
peer returns k's corresponding list of values. The node terminates
its search
and get
returns. The requesting client application handles these redundant
references
in some application-specific way, e.g.,
CoralProxy contacts multiple sources in parallel to download cached content.
Multiple stores of the same key will be spread over multiple nodes.
The pointers retrieved by the application are thus distributed among
those stored, providing load balancing both within Coral and
between servers using Coral.
4.3 Hierarchical Operations
For locality-optimized routing and data placement,
Coral uses
several levels of DSHTs called clusters.
Each level-i cluster is named by a randomly-chosen 160-bit cluster
identifier; the level-0 cluster ID is predefined as 0160.
Recall that a set of nodes should form a cluster if their average,
pair-wise RTTs are below some threshold. As mentioned earlier, we describe
a three-level hierarchy with thresholds of inf,
60 msec, and 20 msec for level-0, -1, and -2 clusters respectively.
In Section 6, we present experimental evidence to the
client-side benefit of clustering.
Figure 3 illustrates Coral's hierarchical routing
operations. Each Coral node has the same node ID in all clusters to
which it belongs; we can view a node as projecting its presence to the
same location in each of its clusters. This structure
must be reflected in Coral's basic routing infrastructure, in
particular to support switching between a node's distinct DSHTs
midway through a lookup.3
Figure 3: Coral's hierarchical routing structure. Nodes use
the same IDs in each of their clusters; higher-level clusters
are naturally sparser. Note that a node can be
identified in a cluster by its shortest unique ID prefix, e.g., ``11'' for R in its level-2 cluster; nodes sharing ID
prefixes are located on common subtrees and are
closer in the XOR metric.
While higher-level neighbors usually share lower-level clusters
as shown, this is not necessarily so. RPCs for a
retrieval on key k are sequentially numbered.
The Hierarchical Retrieval Algorithm.
A requesting node R specifies the starting and stopping levels at
which Coral should search. By default, it initiates the get
query on its highest (level-2) cluster to try to take advantage of
network locality. If routing RPCs on this cluster hit some node
storing the
key k (RPC 1 in Fig. 3), the lookup halts and returns the
corresponding stored value(s)---a hit---without ever searching
lower-level clusters.
If a key is not found, the lookup will reach k's closest node C2
in this cluster (RPC 2), signifying
failure at this level. So, node R continues the search in
its level-1 cluster. As these clusters are very often concentric,
C2 likely exists at the identical location
in the identifier space in all clusters, as shown. R begins
searching onward from C2 in its level-1 cluster (RPC 3), having
already traversed the ID-space up to C2's prefix.
Even if the search eventually switches to the global cluster (RPC 4),
the total number of RPCs required is about the same as a single-level
lookup service, as a lookup continues from the point at which it left
off in the identifier space of the previous cluster. Thus,
(1) all lookups at the beginning are fast, (2) the system can tightly
bound RPC timeouts, and (3) all pointers in higher-level clusters
reference data within that local cluster.
The Hierarchical Insertion Algorithm.
A node starts by performing a put on its level-2 cluster as in
Section 4.2, so that other nearby nodes can take advantage
of locality. However, this placement is only ``correct'' within the
context of the local level-2 cluster. Thus, provided that the key is
not already loaded, the node continues its insertion in the level-1
cluster from the point at which the key was inserted in level 2, much
as in the retrieval case. Again, Coral traverses the ID-space only
once.
As illustrated in Figure 3,
this practice results in a loose hierarchical cache, whereby a
lower-level cluster contains nearly all data stored in the
higher-level clusters to which its members also belong.
To enable such cluster-aware behavior, the headers of every Coral RPC
include the sender's cluster information: the
identifier, age, and a size estimate of each of its non-global
clusters. The recipient uses this information to demultiplex requests
properly, i.e., a recipient should only consider a put and
get for those levels on which it shares a cluster with the sender.
Additionally, this information drives routing table management: (1)
nodes are added or removed from the local cluster-specific routing
tables accordingly; (2) cluster information is accumulated to drive
cluster management, as described next.
4.4 Joining and Managing Clusters
As in any peer-to-peer system, a peer contacts an existing node to
join the system. Next, a new node makes several queries to seed its
routing tables. However, for non-global clusters, Coral adds one
important requirement: A node will only join an acceptable
cluster,
where acceptability requires that the latency to 80% of the nodes be
below the cluster's threshold. A node can easily determine whether
this condition holds by recording minimum round-trip-times (RTTs) to
some subset of nodes belonging to the cluster.
While nodes learn about clusters as a side effect of normal lookups,
Coral also exploits its DSHTs to store hints.
When Coral starts up, it uses its built-in fast traceroute
mechanism (described in Section 3.1) to determine the
addresses of routers up to five hops out. Excluding any private
(``RFC1918'') IP addresses, Coral uses these router addresses as
keys under which to index clustering hints in its
DSHTs. More specifically, a node R stores mappings from each
router address to its own IP address and UDP port number. When a
new node S, sharing a gateway with R, joins the network, it will
find one or more of R's hints and quickly cluster with it, assuming
R is, in fact, near S.
In addition, nodes store mappings to themselves using as keys any IP
subnets they directly connect to and the 24-bit prefixes of gateway
router addresses. These prefix hints are of use to
Coral's level function, which traceroutes clients in the
other direction; addresses on forward and reverse traceroute paths
often share 24-bit prefixes.
Nodes continuously collect clustering information from peers: All RPCs
include round-trip-times, cluster membership, and estimates of cluster
size. Every
five minutes, each node
considers changing its cluster membership based on this collected
data. If this collected data indicates that an alternative candidate cluster
is desirable, the node first validates the collected data
by contacting several nodes within the candidate cluster by routing to
selected keys.
A node can also form a new singleton
cluster when 50% of its accesses to members of its present cluster do
not meet the RTT constraints.
If probes indicate that 80%
of a cluster's nodes are within
acceptable TTLs and the cluster is larger,
it replaces a node's current
cluster. If multiple clusters are acceptable, then Coral chooses
the largest cluster.
Unfortunately, Coral has only rough approximations
of cluster size, based on its routing-table size.
If nearby clusters A and B are of similar sizes, inaccurate
estimations could lead to oscillation as nodes flow
back-and-forth (although we have not observed such behavior). To
perturb an oscillating system into a stable state, Coral employs a
preference function d that shifts every hour. A node selects
the larger cluster only if the following holds:
| log(sizeA) - log(sizeB) |
>
d (min(ageA,ageB))
where age is the current time minus the cluster's creation
time. Otherwise, a node simply selects the cluster with the lower
cluster ID.
We use a square wave function for d that takes a value 0 on
an even number of hours and 2 on an odd number. For clusters of
disproportionate size, the selection function immediately favors the
larger cluster. Otherwise, d's transition perturbs clusters to
a steady state.4
In either case, a node that switches clusters
still remains in the routing tables of nodes in its
old cluster. Thus, old neighbors will still contact it and learn of
its new, potentially-better, cluster. This produces an avalanche
effect as more and more nodes switch to the larger cluster.
This merging of clusters is very beneficial. While a small cluster
diameter provides fast lookup, a large cluster capacity increases the
hit rate.
5 Implementation
The Coral indexing system is composed of a client library and
stand-alone daemon. The simple client library allows applications,
such as our DNS server and HTTP proxy, to connect to and interface
with the Coral daemon. Coral is 14,000 lines of C++, the DNS
server, dnssrv, is 2,000 lines of C++, and the HTTP proxy is an
additional 4,000 lines. All three components use the asynchronous I/O
library provided by the SFS toolkit [19] and are
structured by asynchronous events and callbacks. Coral network
communication is via RPC over UDP. We have successfully run Coral
on Linux, OpenBSD, FreeBSD, and Mac OS X.
6 Evaluation
In this section, we provide experimental results that support our
following hypotheses:
-
CoralCDN dramatically reduces load on servers, solving the
``flash crowd'' problem.
- Clustering provides performance gains for popular data,
resulting in good client performance.
- Coral naturally forms suitable clusters.
- Coral prevents hot spots within its indexing system.
To examine all claims, we present wide-area measurements of a
synthetic work-load on CoralCDN nodes running on PlanetLab, an
internationally-deployed test bed. We use such an experimental setup
because traditional tests for CDNs or web servers are not interesting
in evaluating CoralCDN: (1) Client-side traces generally measure
the cacheability of data and client latencies. However, we are mainly
interested in how well the system handles load spikes. (2)
Benchmark tests such as SPECweb99 measure the web server's
throughput on disk-bound access patterns, while CoralCDN is
designed to reduce load on off-the-shelf web servers that are network-bound.
The basic structure of the experiments were is follows. First, on 166
PlanetLab machines geographically distributed mainly over North
America and Europe, we launch a Coral daemon, as well as a
dnssrv and CoralProxy.
For experiments referred to as multi-level, we configure a
three-level hierarchy by setting the clustering RTT threshold of
level 1 to 60 msec and level 2 to 20 msec. Experiments referred to as
single-level use only the level-0 global cluster. No objects
are evicted from CoralProxy caches during these experiments. For
simplicity, all nodes are seeded with the same well-known host. The
network is allowed to stabilize for 30 minutes.5
Second, we run an unmodified Apache web server sitting behind a DSL
line with 384 Kbit/sec upstream bandwidth, serving 12 different 41KB
files, representing groups of three embedded images referenced by four
web pages.
Third, we launch client processes on each machine that, after an
additional random delay between 0 and 180 seconds for asynchrony,
begin making HTTP GET requests to Coralized URLs. Each client
generates requests for the group of three files, corresponding to a
randomly selected web page, for a period of 30 minutes. While we
recognize that web traffic generally has a Zipf distribution, we are
attempting merely to simulate a flash crowd to a popular web page with
multiple, large, embedded images (i.e., the Slashdot effect).
With 166 clients, we are generating 99.6 requests/sec, resulting
in a cumulative download rate of approximately 32,800 Kb/sec. This
rate is almost two orders of magnitude greater than the origin web
server could handle. Note that this rate was chosen synthetically and
in no way suggests a maximum system throughput.
For Experiment 4 (Section 6.4),
we do not run any such clients. Instead, Coral nodes
generate requests at very high rates, all for the same key, to
examine how the DSHT indexing infrastructure prevents nodes close
to a target ID from becoming overloaded.
![](levelHist.png)
Figure 4: The number of client accesses to CoralProxies and the
origin HTTP server. CoralProxy accesses
are reported relative to the cluster level from which data was
fetched, and do not include requests handled through local caches.
6.1 Server Load
Figure 4 plots the number of requests per minute that
could not be handled by a CoralProxy's local cache.
During the initial minute, 15 requests hit the origin
web server (for 12 unique files). The 3 redundant lookups are due to
the simultaneity at which requests are generated;
subsequently,
requests are handled either through CoralCDN's wide-area cooperative
cache or through a proxy's local cache, supporting our hypothesis that
CoralCDN can migrate load off of a web server.
During this first minute, equal numbers of requests were handled by
the level-1 and level-2 cluster caches. However, as the files
propagated into CoralProxy
caches, requests quickly were resolved within faster level-2
clusters. Within 8-10 minutes, the files became replicated at nearly every
server, so few client requests went further than the proxies' local
caches. Repeated runs of this experiment yielded some variance in the
relative magnitudes of the initial spikes in requests to different
levels, although the number of origin server hits remained
consistent.
![](e2e-lat.png)
![](e2e-lat-asia.png)
Request latency (sec) |
All nodes |
Asian nodes |
|
50% |
96% |
50% |
96% |
single-level |
0.79 |
9.54 |
2.52 |
8.01 |
multi-level |
0.31 |
4.17 |
0.04 |
4.16 |
multi-level, traceroute |
0.19 |
2.50 |
0.03 |
1.75 |
Figure 5: End-to-End client latency for requests for
Coralized URLs, comparing the effect of single-level
vs. multi-level clusters and of using traceroute during DNS
redirection. The top graph includes all nodes; the bottom
only nodes in Asia.
6.2 Client Latency
Figure 5 shows the end-to-end latency for a client to
fetch a file from CoralCDN, following the steps given in
Section 2.2. The top graph shows the latency
across all PlanetLab nodes used in the experiment, the bottom graph
only includes data from the clients located on 5 nodes in Asia (Hong
Kong (2),
Taiwan, Japan, and the Philippines). Because most nodes are located
in the U.S. or Europe, the performance benefit of clustering is much
more pronounced on the graph of Asian nodes.
Recall that this end-to-end latency includes the time for the client
to make a DNS request and to connect to the discovered CoralProxy.
The proxy attempts to fulfill the client request first through its
local cache, then through Coral, and finally through the origin web
server. We note that CoralProxy implements cut-through routing by
forwarding data to the client prior to receiving the entire file.
These figures report three results: (1) the distribution of
latency of clients using only a single level-0 cluster (the solid
line), (2) the
distribution of latencies of clients using multi-level clusters (dashed),
and (3) the same hierarchical network, but using traceroute during DNS
resolution to map clients to nearby proxies (dotted).
All clients ran on the same subnet (and host, in fact) as a
CoralProxy in our
experimental setup. This would not be the case in the real
deployment: We would expect a combination of hosts sharing networks
with CoralProxies---within the same IP prefix as registered with
Coral---and hosts without. Although the multi-level network using
traceroute provides the lowest latency at most percentiles, the
multi-level system without traceroute also performs better than
the single-level system. Clustering has a clear performance
benefit for clients, and this benefit is particularly apparent for
poorly-connected hosts.
![](proxyLat.png)
Figure 6: Latencies for proxy to get keys from Coral.
Figure 6 shows the latency of get operations, as
seen by CoralProxies when they lookup URLs in Coral (Step 8 of
Section 2.2). We plot the get latency on the single
level-0 system vs. the multi-level systems. The
multi-level system is 2-5 times faster up to the 80% percentile.
After the 98% percentile, the single-level system is actually faster:
Under heavy packet loss, the multi-system requires a few more
timeouts as it traverses its hierarchy levels.
![](map-us.png)
Figure 7: World view of level-1 clusters (60 msec threshold), and
United States view of level-2 clusters (20 msec threshold). Each
unique, non-singleton cluster is assigned a letter; the size of the
letter corresponds to collocated nodes in the same cluster.
6.3 Clustering
Figure 7 illustrates a snapshot of the clusters from the
previous experiments, at the time when clients began fetching URLs
(30 minutes out).
This map is meant to provide a qualitative feel for the organic nature
of cluster development, as opposed to offering any quantitative measurements.
On both maps, each unique, non-singleton cluster
within the network is assigned a letter.
We have plotted the location of our nodes by latitude/longitude
coordinates. If two nodes belong to the same cluster, they are
represented by the same letter. As each PlanetLab site
usually collocates several servers, the size of the letter expresses
the number of nodes at that site that belong to the same cluster.
For example, the
very large ``H'' (world map) and ``A'' (U.S. map)
correspond to nodes collocated at
U.C. Berkeley.
We did not include singleton
clusters on the maps to improve readability;
post-run analysis showed that such nodes' RTTs to
others (surprisingly, sometimes even at the same site) were above
the Coral thresholds.
The world map shows that Coral
found natural divisions between sets of nodes along geospatial lines
at a 60 msec threshold.
The map shows several distinct regions, the most dramatic being the
Eastern U.S. (70
nodes), the Western U.S. (37 nodes), and Europe (19 nodes).
The close correlation between network and physical
distance suggests that speed-of-light delays
dominate round-trip-times. Note that, as we did not plot singleton
clusters, the map does not include three Asian nodes (in Japan,
Taiwan, and the Philippines, respectively).
The United States map shows level-2 clusters again roughly separated
by physical locality. The map shows 16 distinct clusters; obvious
clusters include California (22 nodes), the Pacific Northwest (9
nodes), the South, the Midwest, etc. The Northeast Corridor cluster
contains 29 nodes,
stretching from North Carolina to Massachusetts. One
interesting aspect of this map is the three separate, non-singleton
clusters in the San Francisco Bay Area. Close examination of
individual RTTs between these sites shows widely varying latencies;
Coral clustered correctly given the underlying network topology.
![](intense-put.png)
Figure 8: The total number of put RPCs hitting each
Coral node per minute, sorted by distance from node ID to target key.
6.4 Load Balancing
Finally, Figure 8 shows the extent to which a DSHT
balances requests to the same key ID. In this experiment, we ran 3 nodes
on each of the earlier hosts for a total of 494 nodes. We configured
the system as a single level-0 cluster. At the same time, all PlanetLab
nodes began to issue back-to-back put/get requests at their
maximum (non-concurrent) rates.
All operations referenced the same key; the values stored during
put requests were randomized. On average, each node issued 400
put/get operation pairs per second, for a total of
approximately 12 million put/get requests per minute, although
only a fraction hit the network.
Once a node is storing a key, get requests are satisfied
locally. Once it is loaded, each node only allows
the leakage rate B RPCs ``through'' it per minute.
The graphs show the number of put RPCs that hit each node in
steady-state, sorted by the XOR distance of the node's ID to the key.
During the first minute, the closest node received 106 put RPCs.
In the second minute, as shown in Figure 8, the system
reached steady-state with the closest node receiving 83 put RPCs
per minute. Recall that our equation in Section 4.2
predicts that it should receive (B · logn)=108
RPCs per minute. The plot strongly emphasizes the efficacy of
the leakage rate B=12, as the number of RPCs
received by the majority of nodes is a low multiple of 12.
No nodes on the far side of the graph received any RPCs. Coral's
routing algorithm explains this condition: these nodes begin routing
by flipping their ID's most-significant bit to match the key's, and
they subsequently contact a node on the near side.
We have omitted the graph of get RPCs: During the first minute,
the most-loaded node received 27 RPCs; subsequently, the key was
widely distributed and the system quiesced.
7 Related work
CoralCDN builds on previous work in peer-to-peer
systems and web-based content delivery.
7.1 DHTs and directory services
A distributed hash table (DHT) exposes two basic functions to
the application: put(key,value) stores a value at the
specified key ID; get(key) returns this stored
value, just as in a normal hash table. Most DHTs use a key-based
routing layer---such as CAN [25],
Chord [31], Kademlia [17],
Pastry [26], or Tapestry [35]---and
store keys on the node whose ID
is closest to the key. Keys must be well distributed
to balance load among nodes. DHTs often replicate multiply-fetched
key/value pairs for scalability, e.g., by having peers replicate
the pair onto the second-to-last peer they contacted as part of a
get request.
DHTs can act either as actual data stores or merely as directory
services storing pointers. CFS [5] and
PAST [27] take the former approach to build a
distributed file system: They require true read/write consistency
among operations, where writes should atomically replace
previously-stored values, not modify them.
Using the network as a directory service,
Tapestry [35] and Coral relax the
consistency of operations in the network.
To put a key, Tapestry
routes along fast hops between peers, placing at each peer
a pointer back to the sending node, until it reaches the node closest
to the key. Nearby nodes routing to the same key are likely to follow
similar paths and discover these cached pointers.
Coral's flexible clustering provides similar
latency-optimized lookup and data placement,
and its algorithms
prevent multiple stores from forming hot spots.
SkipNet also builds a hierarchy of lookup groups,
although it explicitly groups nodes by domain name to support
organizational disconnect [9].
7.2 Web caching and content distribution
Web caching systems fit within a large class of
CDNs that handle high demand through diverse replication.
Prior to the recent interest in peer-to-peer systems, several projects
proposed cooperative Web caching [2, 7, 8, 16]. These systems either multicast queries or require that
caches know some or all other servers, which worsens their
scalability, fault-tolerance, and susceptibility to hot spots. Although
the cache hit rate of cooperative web caching increases only to a
certain level, corresponding to a moderate population
size [34], highly-scalable cooperative systems can still
increase the total system throughput by reducing server-side load.
Several projects have considered peer-to-peer overlays for web
caching, although all such systems only benefit participating clients
and thus require widespread adoption to reduce server load.
Stading et al. use a DHT to cache
replicas [29], and PROOFS uses a randomized overlay
to distribute popular content [30]. Both systems focus
solely on mitigating flash crowds and suffer from high request
latency. Squirrel proposes web caching on a traditional DHT, although
only for organization-wide networks [10]. Squirrel
reported poor load-balancing when the system stored pointers in the
DHT. We attribute this to the DHT's inability to handle too many
values for the same key---Squirrel only stored 4 pointers per
object---while CoralCDN references many more proxies by storing
different sets of pointers on different nodes. SCAN examined
replication policies for data disseminated through a multicast tree
from a DHT deployed at ISPs [3].
Akamai [1] and other commercial CDNs use DNS redirection
to reroute client
requests to local clusters of machines, having built detailed
maps of the Internet through a combination of BGP feeds and their own
measurements, such as
traceroutes from numerous vantage points [28]. Then,
upon reaching a cluster of collocated machines, hashing
schemes [11, 32] map requests to specific
machines to increase capacity. These systems require deploying large
numbers of highly provisioned servers, and typically result in very
good performance (both latency and throughput) for customers.
Such centrally-managed CDNs appear to offer two benefits over
CoralCDN. (1) CoralCDN's network measurements, via traceroute-like
probing of DNS clients, are somewhat constrained in comparison.
CoralCDN nodes do not have BGP feeds and are under tight latency
constraints to avoid delaying DNS replies while probing.
Additionally, Coral's design assumes that no single node even knows
the identity of all other nodes in the system, let alone their precise
network location. Yet, if many people adopt the system, it will build
up a rich database of neighboring networks. (2) CoralCDN offers
less aggregate storage capacity, as cache management is completely
localized. But, it is designed for a much larger number of machines
and vantage points: CoralCDN may provide better performance for
small organizations hosting nodes, as it is not economically efficient
for commercial CDNs to deploy machines behind most bottleneck links.
More recently, CoDeeN
has provided users with a set of open web proxies [23]. Users can
reconfigure their browsers to use a CoDeeN proxy and subsequently
enjoy better performance. The system has been deployed, and
anecdotal evidence suggests it is very successful at
distributing content efficiently. Earlier simulation
results show that certain policies should
achieve high system throughput and low request latency [33].
(Specific details of the deployed system have not yet been published,
including an Akamai-like service also in development.)
Although CoDeeN gives participating users better
performance to most web sites, CoralCDN's goal is
to gives most users better performance to participating
web sites---namely those whose publishers have ``Coralized''
the URLs. The two design points pose somewhat different challenges.
For instance, CoralCDN takes pains to greatly minimize the load on
under-provisioned origin servers, while CoDeeN has tighter latency
requirements as it is on the critical path for all web requests.
Finally, while CoDeeN has suffered a number of administrative headaches,
many of these problems do not apply to CoralCDN, as, e.g.,
CoralCDN does not allow POST operations or SSL tunneling, and it can be
barred from accessing particular sites without affecting users'
browsing experience.
8 Future Work
Security.
This paper does not address CoralCDN's security issues. Probably
the most important issue is ensuring the integrity of cached data.
Given our experience with spam on the Internet, we should expect that
adversaries will attempt to replace cached data with advertisements for
pornography or prescription drugs.
A solution is future work, but breaks down into three components.
First, honest Coral nodes should not cache invalid data. A
possible solution might include embedding self-certifying
pathnames [20] in Coralized URLs, although this
solution requires server buy-in. Second, Coral nodes should be
able to trace the path that cached data has taken and exclude data from
known bad systems. Third, we should try to prevent clients from using
malicious proxies. This requires client buy-in, but offers additional
incentives for organizations to run Coral: Recall that a
client will access a
local proxy when one is available, or administrators can configure a
local DNS resolver to always return a specific Coral instance.
Alternatively, ``SSL splitting'' [15] provides end-to-end
security between clients and servers, albeit at a higher
overhead for the origin servers.
CoralCDN may require some additional abuse-prevention
mechanisms,
such as throttling bandwidth hogs and restricting
access to address-authenticated content [23].
To leverage our redundant resources, we are considering efficient
erasure coding for large-file
transfers [18].
For such, we have developed on-the-fly verification
mechanisms to limit malicious proxies' abilities to waste
a node's downstream bandwidth [13].
Leveraging the Clustering Abstraction.
This paper presents clustering mainly as a performance optimization
for lookup operations and DNS redirection. However, the clustering
algorithms we use are driven by generic policies that could
allow hierarchy creation based on a variety of criteria. For example,
one could provide a clustering policy by IP routing block or by AS
name, for a simple mechanism that reflects administrative control and
performs well under network partition. Or, Coral's
clusters could be used to explicitly encode a web-of-trust security
model in the system, especially useful given its standard
open-admissions policy. Then, clusters could easily represent trust
relationships, allowing lookups to resolve at the most trustworthy
hosts. Clustering may prove to be a very useful abstraction
for building interesting applications.
Multi-cast Tree Formation.
CoralCDN may transmit multiple requests to an origin HTTP server at
the beginning of a flash crowd. This is caused by a race condition at
the key's closest node, which we could
eliminate by extending store
transactions to provide return status information (like
test-and-set in shared-memory systems).
Similar extensions to store
semantics may be useful for balancing its
dynamically-formed dissemination trees.
Handling Heterogeneous Proxies.
We should consider
the heterogeneity of proxies when performing DNS redirection and
intra-Coral HTTP fetches. We might use some type of feedback-based
allocation policy, as proxies can return their current load and
bandwidth availability, given that they are already probed to
determine liveness.
Deployment and Scalability Studies.
We are planning an initial deployment of CoralCDN as a long-lived
PlanetLab port 53 (DNS) service. In doing so, we hope to gather
measurements from a large, active client population, to better
quantify CoralCDN's scalability and effectiveness:
Given our client-transparency, achieving wide-spread use is much
easier than with most peer-to-peer systems.
9 Conclusions
CoralCDN is a peer-to-peer web-content distribution network that
harnesses people's willingness to redistribute data they themselves find
useful. It indexes cached web content with a new distributed storage
abstraction called a DSHT. DSHTs map a key to multiple values
and can scale to many stores of the same key without hot-spot
congestion. Coral successfully clusters nodes by network diameter,
ensuring that nearby replicas of data can be located and retrieved
without querying more distant nodes. Finally, a peer-to-peer DNS
layer redirects clients to nearby CoralProxies, allowing unmodified
web browsers to benefit from CoralCDN, and more importantly, to
avoid overloading origin servers.
Measurements of CoralCDN demonstrate that it allows under-provisioned
web sites to achieve dramatically higher capacity. A web server
behind a DSL line experiences hardly any load when hit by a
flash crowd with a sustained aggregate transfer rate that is
two orders of magnitude greater than its bandwidth.
Moreover, Coral's clustering mechanism
forms qualitatively sensible geographic clusters and provides
quantitatively better performance than locality-unaware systems.
We have made CoralCDN freely available, so that even people with
slow connections
can publish web sites whose capacity grows
automatically with popularity. Please visit
http://www.scs.cs.nyu.edu/coral/.
Acknowledgments.
We are grateful to Vijay Karamcheti for early conversations that
helped shape this work. We thank David Andersen, Nick Feamster,
Daniel Giffin, Robert Grimm, and our shepherd, Marvin Theimer, for
their helpful feedback on drafts of this paper. Petar Maymounkov and
Max Krohn provided access to Kademlia data structure and HTTP parsing
code, respectively. We thank the PlanetLab support team for allowing
us the use of UDP port 53 (DNS), despite the additional hassle this
caused them.
Coral is part
of project IRIS (http://project-iris.net/), supported by the NSF
under Cooperative Agreement No. ANI-0225660. David Mazières is
supported
by an Alfred P. Sloan Research Fellowship. Michael Freedman is
supported by an NDSEG Fellowship.
References
- [1]
-
Akamai Technologies, Inc.
http://www.akamai.com/, 2004.
- [2]
-
A. Chankhunthod, P. Danzig, C. Neerdaels, M. Schwartz, and K. Worrell.
A hierarchical internet object cache.
In USENIX, Jan 1996.
- [3]
-
Y. Chen, R. Katz, and J. Kubiatowicz.
SCAN: A dynamic, scalable, and efficient content distribution
network.
In Proceedings of the International Conference on Pervasive
Computing, Zurich, Switzerland, Aug 2002.
- [4]
-
M. Crawford.
RFC 2672: Non-terminal DNS name redirection, Aug 1999.
- [5]
-
F. Dabek, M. F. Kaashoek, D. Karger, R. Morris, and Ion Stoica.
Wide-area cooperative storage with CFS.
In SOSP, Banff, Canada, Oct 2001.
- [6]
-
Digital Island, Inc.
http://www.digitalisland.com/, 2004.
- [7]
-
L. Fan, P. Cao, J. Almeida, and A. Z. Broder.
Summary cache: a scalable wide-area web-cache sharing protocol.
Technical Report 1361, CS Dept, U. Wisconson, Madison, Feb 1998.
- [8]
-
S. Gadde, J. Chase, and M. Rabinovich.
A taste of crispy squid.
In Workshop on Internet Server Perf., Madison, WI, Jun 1998.
- [9]
-
N. Harvey, M. Jones, S. Saroiu, M. Theimer, and A. Wolman.
Skipnet: A scalable overlay network with practical locality
properties.
In USITS, Seattle, WA, Mar 2003.
- [10]
-
S. Iyer, A. Rowstron, and P. Druschel.
Squirrel: A decentralized, peer-to-peer web cache.
In PODC, Monterey, CA, Jul 2002.
- [11]
-
D. Karger, E. Lehman, F. Leighton, M. Levine, D. Lewin, and R. Panigrahy.
Consistent hashing and random trees: Distributed caching protocols
for relieving hot spots on the World Wide Web.
In STOC, May 1997.
- [12]
-
D. Karger, A. Sherman, A. Berkheimer, B. Bogstad, R. Dhanidina, K. Iwamoto,
B. Kim, L. Matkins, and Y. Yerushalmi.
Web caching with consistent hashing.
WWW8 / Computer Networks, 31(11--16):1203--1213, 1999.
- [13]
-
M. Krohn, M. J. Freedman, and D. Mazières.
On-the-fly verification of rateless erasure codes for efficient
content distribution.
In IEEE Symp. on Security and Privacy, Oakland, CA, May 2004.
- [14]
-
J. Kubiatowicz, D. Bindel, Y. Chen, S. Czerwinski, P. Eaton, D. Geels,
R. Gummadi, S. Rhea, H. Weatherspoon, W. Weimer, C. Wells, and B. Zhao.
OceanStore: An architecture for global-scale persistent storage.
In ASPLOS, Cambridge, MA, Nov 2000.
- [15]
-
C. Lesniewski-Laas and M. F. Kaashoek.
SSL splitting: Securely serving data from untrusted caches.
In USENIX Security, Washington, D.C., Aug 2003.
- [16]
-
R. Malpani, J. Lorch, and D. Berger.
Making world wide web caching servers cooperate.
In WWW, Apr 1995.
- [17]
-
P. Maymounkov and D. Mazières.
Kademlia: A peer-to-peer information system based on the xor metric.
In IPTPS, Cambridge, MA, Mar 2002.
- [18]
-
P. Maymounkov and D. Mazières.
Rateless codes and big downloads.
In IPTPS, Berkeley, CA, Feb 2003.
- [19]
-
D. Mazières.
A toolkit for user-level file systems.
In USENIX, Boston, MA, Jun 2001.
- [20]
-
D. Mazières and M. F. Kaashoek.
Escaping the evils of centralized control with self-certifying
pathnames.
In ACM SIGOPS European Workshop, Sep 1998.
- [21]
-
Mirror Image Internet.
http://www.mirror-image.com/, 2004.
- [22]
-
FIPS Publication 180-1: Secure Hash Standard.
National Institute of Standards and Technology (NIST), Apr 1995.
- [23]
-
V. Pai, L. Wang, K. Park, R. Pang, and L. Peterson.
The dark side of the web: An open proxy's view.
In HotNets, Cambridge, MA, Nov 2003.
- [24]
-
G. Pfister and V. A. Norton.
``hot spot'' contention and combining in multistage interconnection
networks.
IEEE Trans. on Computers, 34(10), Oct 1985.
- [25]
-
S. Ratnasamy, P. Francis, M. Handley, R. Karp, and S. Shenker.
A scalable content-addressable network.
In ACM SIGCOMM, San Diego, CA, Aug 2001.
- [26]
-
A. Rowstron and P. Druschel.
Pastry: Scalable, distributed object location and routing for
large-scale peer-to-peer systems.
In Proc. IFIP/ACM Middleware, Nov 2001.
- [27]
-
A. Rowstron and P. Druschel.
Storage management and caching in PAST, a large-scale, persistent
peer-to-peer storage utility.
In SOSP, Banff, Canada, Oct 2001.
- [28]
-
N. Spring, R. Mahajan, and D. Wetherall.
Measuring ISP topologies with Rocketfuel.
In SIGCOMM, Pittsburgh, PA, Aug 2002.
- [29]
-
T. Stading, P. Maniatis, and M. Baker.
Peer-to-peer caching schemes to address flash crowds.
In IPTPS, Cambridge, MA, Mar 2002.
- [30]
-
A. Stavrou, D. Rubenstein, and S. Sahu.
A lightweight, robust p2p system to handle flash crowds.
In IEEE ICNP, Paris, France, Nov 2002.
- [31]
-
I. Stoica, R. Morris, D. Liben-Nowell, D. Karger, M. F. Kaashoek, F. Dabek, and
H. Balakrishnan.
Chord: A scalable peer-to-peer lookup protocol for internet
applications.
In IEEE/ACM Trans. on Networking, 2002.
- [32]
-
D. Thaler and C. Ravishankar.
Using name-based mappings to increase hit rates.
IEEE/ACM Trans. on Networking, 6(1):1--14, 1998.
- [33]
-
L. Wang, V. Pai, and L. Peterson.
The effectiveness of request redirection on cdn robustness.
In OSDI, Boston, MA, Dec 2002.
- [34]
-
A. Wolman, G. Voelker, N. Sharma, N. Cardwell, A. Karlin, and H. Levy.
On the scale and performance of cooperative web proxy caching.
In SOSP, Kiawah Island, SC, Dec 1999.
- [35]
-
B. Zhao, L. Huang, J. Stribling, S. Rhea, A. Joseph, and J. Kubiatowicz.
Tapestry: A resilient global-scale overlay for service deployment.
IEEE J. Selected Areas in Communications, 2003.
- 1
- While
Coral's HTTP proxy definitely provides proxy functionality, it is
not an HTTP proxy in the strict RFC2616
sense; it serves requests that are syntactically formatted for an
ordinary HTTP server.
- 2
- Experiments in
this paper use b=1.
- 3
- We initially built Coral using
the Chord [31] routing layer as a block-box; difficulties
in maintaining distinct clusters and the complexity of the subsequent
system caused us to scrap the implementation.
- 4
- Should clusters of similar size continuously
exchange members when d is zero, as soon as d
transitions, nodes will all flow to the cluster with the lower cluster
id. Should the clusters oscillate when d=2 (as the estimations
``hit'' with one around 22-times larger), the nodes will all flow
to the larger one when d returns to zero.
- 5
- The
stabilization time could be made shorter by reducing the clustering
period (5 minutes). Additionally, in real applications, clustering is
in fact a simpler task, as new nodes would immediately join nearby
large clusters as they join the pre-established system. In our setup,
clusters develop from an initial network comprised entirely of
singletons.
This document was translated from LATEX by
HEVEA.
|
